High Light Intelligence Technology, a pioneer in the CVD diamond industry, has advanced MPCVD technology and CVD diamond production workshops. We focus on producing high-purity lab-grown diamonds for the jewelry industry, and at the same time create industrial-grade CVD diamond products, covering single crystals, polycrystalline, films and diamond surface metallization. We also provide 6kw/10kw/15kw MPCVD equipment to help customers in all aspects, from equipment to products, and then to all-round services, to create brilliance together.

At the exhibition, we will fully display our latest research and development results and products, including industrial diamond products, jewelry lab-grown diamond products, etc., so that you can experience our technical strength and product advantages in person. In particular, our major breakthrough in the field of MPCVD equipment -- the newly upgraded 10kw 90mm diameter deposition area MPCVD equipment and the latest 15kw 100mm deposition area MPCVD equipment.


We sincerely invite you to experience the innovative achievements of High Light Intelligence Technology in the field of carbon materials, and provide one-on-one consultation with a professional team on site to explore development trends. The exhibition will also hold technical seminars and business negotiations to promote industry exchanges and seek future cooperation.
We firmly believe that your participation will add infinite brilliance to the conference and will also bring new opportunities and inspiration for the development of you and your company. Let us gather in Shanghai to jointly open a new chapter in carbon material technology and create a better future together!

●●○

Time:
2024/12/05-07

Location:
Shanghai New International Expo Centre

Theme:
New track · New opportunities · New growth
